Freeze Dryer

Applicable to biological research, medical laboratories for drying of biotechnological and pharmaceutical products, e.g. tissues and tissue extracts, bacteria, vaccines, and sera, also suitable to food research, chemical industry and other related scenarios for efficient lyophilization of samples.

Product Features

DG-65Z04-10A

Automatic parameter storage

Intelligent storage of the freeze-drying parameters, without setting them separately each time
DG-65Z04-10A

The integrated design and totally enclosed environment make the sample pollution-free

The whole working cabin is closed, the freeze-drying process is isolated from the outside environment
DG-65Z04-10A

Multiple alarm functions

Multiple alarms including cold trap cooling overtime, vacuum pump oil replacement reminder, temperature sensor fault/cold trap temperature sensor fault, vacuum sensor fault, condenser sensor fault, ambient temperature sensor fault, abnormal refrigeration, motor overcurrent, condenser dirty blockage, vacuum alarm, heating lamp life less than 10% alarm


DG-65Z04-10A

The refrigeration efficiency is greatly improved

The evaporator is located in the freezing chamber, which directly cools the sample and improves the refrigeration efficiency, it can reach-60°C within 25 minutes
DG-65Z04-10A

IoT real-time management

Separate account, authority management, configuration record function, data traceability, real-time monitoring of equipment status
DG-65Z04-10A

High sublimation speed and high drying  efficiency

Excellent temperature uniformity, free from external influences, more energy-saving and environment-friendly

Specifications

Model Ice Condenser Temperature (°C) Condensation Efficiency Power Supply (V/Hz) Weight (kg) Exterior Dimension (W*D*H)(mm)
DG-65Z04-10A -65 4kg/24h 220/50 145 (Equipment)+25 (Pump) 480*793*883 (without pump)
DG-65Z04-10AR -65/-85 (Optional) 4kg/24h 220/50 65 (Equipment)+25 (Pump) 480*793*730 (without pump)

Resources

There is no information available, please submit your request or contact us to get more details.

Freeze Dryer DG-65Z04-10AR
Freeze Dryer DG-65Z04-10A
1
DG-65Z04-10A Operation Manual
1
DG-65Z04-10A Safety Test Report
DG-65Z04-10A EMC Report
DG-65Z04-10A UKCA Certificate
DG-65Z04-10A CE Certificate 1
DG-65Z04-10A CE Certificate 2
1
DG-65Z04-10A Images
